MAX77801EWP+T
RoHS
RoHS compliant
RoHS compliantPackage 20-WFBGA, WLBGA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
MAX77801 Tape & Reel (TR) Active Step-Up/Step-Down DC to DC switching regulator 3.8V 0.69mm 2A 2.5MHz
PDF
/
Buying Options
Total Price: USD $1.65
Unit Price: USD $1.6544
≥1 USD $1.6544
≥10 USD $1.48368
≥100 USD $1.399904
≥500 USD $1.192664
≥1000 USD $1.119888
≥3000 USD $0.979898
Inventory: 1117
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.69mm
Technical
Min Output Voltage 2.6V
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 2.5MHz
Control Mode CURRENT-MODE
Topology Buck-Boost
Voltage - Output (Min/Fixed) 2.6V
Max Output Voltage 4.19V
Current - Output 2A
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 3.8V
Voltage - Input (Min) 2.3V
Output Type Programmable
Output Voltage 3.3V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Function Step-Up/Step-Down
JESD-30 Code R-PBGA-B20
Base Part Number MAX77801
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.4mm
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BALL
Terminal Position BOTTOM
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Package / Case 20-WFBGA, WLBGA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
