ATMEGA128A-MNR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant NO LEAD QUAD CMOS Microcontroller -40C~105C TA 16MHz 1mm 4K x 8
PDF
/
Inventory: 7912
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mounting Type Surface Mount
Package / Case 64-VFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Published 2003
Series AVR? ATmega
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Additional Feature ALSO OPERATES WITH 2.7V MIN @ 8MHZ
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 5V
Terminal Pitch 0.5mm
On Chip Program ROM Width 8
EEPROM Size 4K x 8
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Data Converter A/D 8x10b
Bit Size 8
Connectivity EBI/EMI, I2C, SPI, UART/USART
Program Memory Size 128KB 64K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor AVR
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
RAM Size 4K x 8
Number of I/O 53
Oscillator Type Internal
Memory Size 128kB
Interface EBI/EMI, I2C, SPI, UART, USART
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code S-XQCC-N64
Base Part Number ATMEGA128A
Frequency 16MHz
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 9mm
Height Seated (Max) 1mm
