AT91SAM7X512B-CU
RoHS
RoHS compliant
RoHS compliantPackage 100-TFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 512KB FLASH 100BGA
PDF
/
Inventory: 5612
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Plating Copper, Silver, Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 100-TFBGA
Number of Pins 100
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Published 1997
Series SAM7X
JESD-609 Code e2
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Terminal Finish Tin/Silver/Copper/Nickel (Sn/Ag/Cu/Ni)
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.8V
Frequency 55MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number AT91SAM7X512
Operating Supply Voltage 1.8V
Supply Voltage-Max (Vsup) 1.95V
Interface CAN, Ethernet, I2C, I2S, Parallel, SPI, UART, USART, USB
Memory Size 512kB
Oscillator Type Internal
Number of I/O 62
Speed 50 MHz
RAM Size 128K x 8
Voltage - Supply (Vcc/Vdd) 1.65V~1.95V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM7?
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16/32-Bit
Program Memory Size 512KB 512K x 8
Connectivity CANbus, Ethernet, I2C, SPI, SSC, UART/USART, USB
Bit Size 32
Data Converter A/D 8x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
Number of Timers/Counters 3
Core Architecture ARM
Number of ADC Channels 8
Dimensions
Height Seated (Max) 1.1mm
Length 9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
