MB90F347CASPFR-GSE1
RoHS
/
Package QFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
F2MC-16LX F2MC-16LX MB90340 Microcontroller IC 16-Bit 24MHz 128KB (128K x 8) FLASH 100-QFP (14x20)
PDF
/
Inventory: 5909
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 20mm
Height Seated (Max) 3.35mm
Technical
Number of Programmable I/O 82
Address Bus Width 24
Number of Timers/Counters 7
DAC Channels YES
PWM Channels NO
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Frequency (Max) 24MHz
Bit Size 16
Peripherals DMA, POR, WDT
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Memory Type FLASH
RAM Size 6kB
Number of I/O 82
Oscillator Type External
Memory Size 128kB
Interface CAN, EBI/EMI, I2C, LIN, SCI, UART, USART
Temperature Grade INDUSTRIAL
Operating Supply Voltage 5V
Frequency 24MHz
Terminal Pitch 0.65mm
Supply Voltage 4V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
HTS Code 8542.31.00.01
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Terminal Finish TIN LEAD
ECCN Code EAR99
Number of Terminations 100
JESD-609 Code e0
Published 2003
Physical
Number of Pins 100
Surface Mount YES
Package / Case QFP
