CY8C4245LQI-483
RoHS
RoHS compliant
RoHS compliantPackage 40-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 32KB FLASH 40QFN
PDF
/
Buying Options
Total Price: USD $4.71
Unit Price: USD $4.708
≥1 USD $4.708
≥10 USD $4.23104
≥100 USD $3.999424
≥500 USD $3.46632
≥1000 USD $3.28856
≥3000 USD $2.950816
Inventory: 1488
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 6mm
Height Seated (Max) 0.6mm
Technical
Bus Compatibility I2C; IDE; IRDA; LIN; SPI; UART
Number of Serial I/Os 3
Boundary Scan NO
Core Architecture ARM
Number of Timers/Counters 4
Data Bus Width 32b
Watchdog Timer Yes
Data Converter A/D 8x12b SAR; D/A 2xIDAC
Supply Current-Max 13.8mA
Connectivity I2C, IrDA, LINbus, Microwire, SmartCard, SPI, SSP, UART/USART
Program Memory Size 32KB 32K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, CapSense, LCD, LVD, POR, PWM, WDT
Core Processor ARM? Cortex?-M0
uPs/uCs/Peripheral ICs Type MULTIFUNCTION PERIPHERAL
Voltage - Supply (Vcc/Vdd) 1.71V~5.5V
Memory Type FLASH, SRAM
RAM Size 4K x 8
Number of I/O 34
Oscillator Type Internal
Memory Size 32kB
Interface I2C, SPI, UART
Supply Voltage-Max (Vsup) 5.5V
Operating Supply Voltage 1.8V
Pin Count 40
Base Part Number CY8C4245
Frequency 48MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Position QUAD
Technology CMOS
ECCN Code 3A991.A.3
Number of Terminations 40
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e4
Series PSOC? 4 CY8C42xx
Published 2005
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Weight 117.310327mg
Number of Pins 40
Package / Case 40-UFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Factory Lead Time 13 Weeks
