XC4010XL-09TQ144C
RoHS
/
Package 144-LQFP
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
XC4000E/X XC4010XL 144-LQFP Tin/Lead (Sn85Pb15) field programmable gate array 1.6mm 3.3V 217MHz 1.2ns
PDF
/
Inventory: 4886
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 144-LQFP
Number of Pins 144
Technical
Operating Temperature 0°C~85°C TJ
Packaging Tray
Published 1999
Series XC4000E/X
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 144
Terminal Finish Tin/Lead (Sn85Pb15)
Additional Feature TYPICAL GATES = 7000-20000
Subcategory Field Programmable Gate Arrays
Technology CMOS
Voltage - Supply 3V~3.6V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 225
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number XC4010XL
Pin Count 144
Number of Outputs 160
Operating Supply Voltage 3.3V
Number of I/O 113
RAM Size 1.6kB
Clock Frequency 217MHz
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 950
Total RAM Bits 12800
Number of Gates 10000
Number of LABs/CLBs 400
Speed Grade 9
Number of Registers 1120
Combinatorial Delay of a CLB-Max 1.2 ns
Number of CLBs 400
Number of Logic Cells 400
Number of Equivalent Gates 7000
Dimensions
Height Seated (Max) 1.6mm
Length 20mm
Width 20mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
