EP3C16E144C7
RoHS
/
Package 144-LQFP Exposed Pad
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Cyclone? III EP3C16 144-LQFP Exposed Pad TIN LEAD field programmable gate array 1.65mm 1.2V 472.5MHz 0C~85C TJ
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.028109
≥1 USD $0.028109
≥500 USD $0.020661
≥1000 USD $0.017227
≥2000 USD $0.015796
≥5000 USD $0.014768
≥10000 USD $0.013739
≥15000 USD $0.013278
≥50000 USD $0.01306
Inventory: 5792
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Surface Mount
Package / Case 144-LQFP Exposed Pad
Surface Mount YES
Technical
Operating Temperature 0°C~85°C TJ
Packaging Tray
Series Cyclone? III
JESD-609 Code e0
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 144
ECCN Code 3A991
Terminal Finish TIN LEAD
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Technology CMOS
Voltage - Supply 1.15V~1.25V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 220
Supply Voltage 1.2V
Terminal Pitch 0.4mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number EP3C16
JESD-30 Code S-PQFP-G144
Number of Outputs 84
Qualification Status Not Qualified
Number of I/O 84
Clock Frequency 472.5MHz
Number of Inputs 84
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 15408
Total RAM Bits 516096
Number of LABs/CLBs 963
Dimensions
Height Seated (Max) 1.65mm
Length 20mm
Width 20mm
Compliance
RoHS Status Non-RoHS Compliant
