EP4CE40F23C8LN
RoHS
/
Package BGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Lead Free OTHER 2003 RoHS Compliant FPGA 85C 141.8kB 200MHz 1.2V
PDF
/
Inventory: 6985
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Package / Case BGA
Number of Pins 484
Technical
Published 2003
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3
Number of Terminations 484
ECCN Code 3A001.A.7.A
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 85°C
Min Operating Temperature 0°C
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Supply Voltage 1V
Terminal Pitch 1mm
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 484
Number of Outputs 331
Qualification Status Not Qualified
Operating Supply Voltage 1.2V
Supply Voltage-Max (Vsup) 1.03V
Power Supplies 11.2/3.32.5V
Temperature Grade OTHER
Memory Size 141.8kB
Number of I/O 328
RAM Size 141.8kB
Frequency (Max) 200MHz
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 39600
Number of Logic Blocks (LABs) 2475
Dimensions
Height Seated (Max) 2.4mm
Length 23mm
Width 23mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
