ATF750LVC-15PU
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
NO 24-DIP (0.300 7.62mm) 1997 ATF750 complex programmable logic device 71MHz 31.877mm 15ns 3V~5.5V
PDF
/
Buying Options
Total Price: USD $3.69
Unit Price: USD $3.6872
≥1 USD $3.6872
≥10 USD $3.3528
≥100 USD $3.223
Inventory: 241
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.62mm
Length 31.877mm
Height Seated (Max) 5.334mm
Technical
Voltage Supply - Internal 3V~5.5V
Number of Dedicated Inputs 11
JTAG BST NO
Number of Macro Cells 10
Output Function MACROCELL
Speed Grade 15
Number of Gates 500
Turn On Delay Time 15 ns
Propagation Delay 15 ns
Memory Type EEPROM
Number of I/O 10
Min Supply Voltage 3V
Max Supply Voltage 3.6V
Programmable Type In System Programmable (min 1K program/erase cycles)
Operating Supply Voltage 3.3V
Base Part Number ATF750
Frequency 71MHz
Terminal Pitch 2.54mm
Supply Voltage 3.3V
Terminal Position DUAL
Technology CMOS
Subcategory Programmable Logic Devices
Additional Feature NO
Terminal Finish Matte Tin (Sn)
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series ATF750LVC
Published 1997
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 24
Package / Case 24-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 18 Weeks
