M4A5-256/128-12YNI image
Favorite
M4A5-256/128-12YNI image
Favorite
RoHS
RoHS RoHS compliant
Package 208-BFQFP
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description YES 208-BFQFP 1998 M4A5-256 complex programmable logic device 100MHz 28mm 12ns 5V
PDF
/
Buying Options
Total Price: USD $59.07
Unit Price: USD $59.0653
≥1 USD $59.0653
≥10 USD $48.46425
≥100 USD $46.94995
≥500 USD $45.43565
≥1000 USD $43.9204
Inventory: 1120
Minimum: 1
-
+

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 208-BFQFP
Number of Pins 208

Technical

Operating Temperature -40°C~85°C TA
Packaging Tray
Published 1998
Series ispMACH? 4A
JESD-609 Code e3
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 208
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature YES
HTS Code 8542.39.00.01
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Supply Voltage 5V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number M4A5-256
Pin Count 208
Qualification Status Not Qualified
Operating Supply Voltage 5V
Power Supplies 5V
Programmable Type In System Programmable
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Number of I/O 128
Memory Type EEPROM
Propagation Delay 12 ns
Turn On Delay Time 12 ns
Number of Gates 10000
Max Frequency 100MHz
Output Function MACROCELL
Number of Macro Cells 256
JTAG BST YES
Number of Dedicated Inputs 14
Voltage Supply - Internal 4.5V~5.5V

Dimensions

Height Seated (Max) 4.1mm
Length 28mm
Width 28mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
