EPM3064ATI44-10N
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
YES 44-TQFP 1998 EPM3064 complex programmable logic device 100MHz 10mm 10ns 2.5/3.33.3V
PDF
/
Buying Options
Total Price: USD $85.36
Unit Price: USD $85.3632
≥1 USD $85.3632
≥10 USD $82.60915
≥100 USD $79.8551
≥500 USD $71.59485
Inventory: 1609
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 1.27mm
Technical
Number of Logic Elements/Blocks 4
Delay Time tpd(1) Max 10ns
Voltage Supply - Internal 3V~3.6V
JTAG BST YES
Number of Macro Cells 64
Output Function MACROCELL
Number of Gates 1250
Propagation Delay 10 ns
Clock Frequency 100MHz
Number of I/O 34
Programmable Type In System Programmable
Supply Voltage-Min (Vsup) 3V
Power Supplies 2.5/3.33.3V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
Base Part Number EPM3064
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code compliant
Terminal Pitch 0.8mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Programmable Logic Devices
Additional Feature YES
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e3
Series MAX? 3000A
Published 1998
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 44-TQFP
Mounting Type Surface Mount
