LTP-757C
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
DISPLAY DOT MATRX RED LC .70"5X7
PDF
/
Inventory: 6155
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 17.22mm
Height 6.35mm
Technical
Internal Connection Common Anode Row, Common Cathode Column
Dominant Wavelength 638 nm
Reverse Voltage 5V
Luminous Intensity 9 mcd
Test Current 20mA
Forward Current 14mA
Voltage - Forward (Vf) (Typ) 1.8V
Power Dissipation 32mW
Element Configuration Common Cathode
Configuration 5 x 7
Number of Elements 35
Reach Compliance Code unknown
Depth 12.66mm
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.50Lx0.70W x 0.25 H 12.66mmx17.74mmx6.30mm
Published 2000
Physical
Number of Pins 12
Package / Case Module
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
