HDSP-2500
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
Alphanumeric Displays Panel 8DIGIT 280LED Orange 28-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $153.09
Unit Price: USD $153.088079
≥1 USD $153.088079
≥200 USD $61.083985
≥500 USD $59.042426
≥1000 USD $58.034119
Inventory: 5326
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Through Hole
Package / Case DIP
Number of Pins 28
Technical
Packaging Rail/Tube
Series HDSP-250x
Size / Dimension 2.79Lx0.76W x 0.26 H 70.87mmx19.41mmx6.60mm
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
ECCN Code EAR99
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -45°C
Color Orange
Additional Feature TTL COMPATIBLE
HTS Code 8531.20.00.40
Subcategory LED Displays
Voltage - Rated DC 5V
Number of Functions 1
Depth 19.58mm
Number of Elements 280
Configuration 5 x 7
Interface Parallel, 8-Bit
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Forward Voltage 5V
Luminous Intensity 7.5 mcd
Millicandela Rating 2.50mcd ~ 20.28mcd
Wavelength - Peak 600 nm
Number of Characters 8
Dominant Wavelength 602 nm
Dimensions
Height 6.604mm
Character Height 6.86mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
