HDLS-1414
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description
LED Displays & Accessories Red 637nm 1x4 Alphanumeric
PDF
/
Buying Options
Total Price: USD $34.21
Unit Price: USD $34.2144
≥1 USD $34.2144
≥10 USD $26.73264
≥100 USD $25.396008
Inventory: 143
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case DIP
Number of Pins 12
Technical
Series HDLx-1414
Size / Dimension 0.70Lx0.79W x 0.24 H 17.66mmx20.12mmx6.10mm
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
HTS Code 8531.20.00.40
Subcategory LED Displays
Voltage - Rated DC 5V
Number of Functions 4
Depth 17.66mm
Operating Supply Voltage 5V
Number of Elements 140
Configuration 5 x 7
Interface 7-Bit ASCII
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Forward Voltage 5V
Luminous Intensity 12.7 mcd
Millicandela Rating 3.97mcd ~ 36.49mcd
Wavelength - Peak 645 nm
Display Type Dot Matrix
Number of Characters 4
Dominant Wavelength 637 nm
Dimensions
Height 6.096mm
Viewing Area (height) 3.7mm
Character Height 3.7mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
