HDLG-2416-FG000

Broadcom Limited
RoHS
RoHS RoHS compliant
Package DIP
Category Optoelectronics / Display Modules - LED Dot Matrix and Cluster
Description LED Displays & Accessories Green 574nm 1x4 Alphanumeric
PDF
/
Buying Options
Total Price: USD $66.81
Unit Price: USD $66.809542
≥1 USD $66.809542
≥200 USD $26.657122
≥500 USD $25.766975
≥1000 USD $25.327154
Inventory: 9619
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Character Height 5mm
Viewing Area (height) 5.08mm
Height 6.604mm

Technical

Dominant Wavelength 574 nm
Number of Characters 4
Wavelength 568 nm
Millicandela Rating 1.20mcd ~ 13.30mcd
Luminous Intensity 13.3 mcd
Forward Voltage 7V
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Interface 7-Bit ASCII
Configuration 5 x 7
Number of Elements 140
Operating Supply Voltage 5V
Depth 18.6mm
Number of Functions 4
Subcategory LED Displays
HTS Code 8531.20.00.40
Additional Feature BUILT-IN MEMORY, WITH DECODER/DRIVER
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.99Lx0.79W x 0.26 H 25.15mmx20.07mmx6.60mm
Series HDLx-2416

Physical

Number of Pins 18
Package / Case DIP
Mount Through Hole

Supply Chain

Factory Lead Time 16 Weeks
