TDSO1150-K
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Orange Red CA 10-Pin DIP
PDF
/
Buying Options
Total Price: USD $1.99
Unit Price: USD $1.9888
≥1 USD $1.9888
≥10 USD $1.3288
≥100 USD $1.02256
≥500 USD $0.924352
≥1000 USD $0.794367
≥3000 USD $0.751036
Inventory: 127
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Package / Case DIP
Number of Pins 10
Technical
Packaging Bulk
Published 2014
Series TDS.11
Size / Dimension 0.389 Hx0.291W x 0.236 D 9.90mmx7.40mmx6.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color Orange-Red
Depth 7.4mm
Number of Elements 8
Power Dissipation-Max 400mW
Element Configuration Common Anode
Power Dissipation 400mW
Voltage - Forward (Vf) (Typ) 2V
Forward Current 17mA
Current - Test 20mA
Forward Voltage 2V
Luminous Intensity 3.6 mcd
Millicandela Rating 3.6mcd
Wavelength - Peak 630nm
Display Type 7-Segment
Reverse Voltage 15V
Wavelength 631 nm
Number of Characters 1
Digit/Alpha Size 0.28 7.00mm
Common Pin Common Anode
Dominant Wavelength 625 nm
Dimensions
Height 9.8806mm
Length 9.9mm
Width 7.3914mm
Viewing Area (height) 7mm
Character Height 7mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
