LB-602VA2 image
Favorite
LB-602VA2 image
Favorite
RoHS
RoHS RoHS compliant
Package 18-DIP
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY 7SEG 14.3MM 2DGT RED CA
PDF
/
Buying Options
Total Price: USD $2.87
Unit Price: USD $2.8688
≥1 USD $2.8688
≥10 USD $2.03104
≥100 USD $1.7028
Inventory: 504
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Character Height 14.3mm
Height 18.9992mm

Technical

Character Width 8mm
Common Pin Common Anode
Digit/Alpha Size 0.56 14.30mm
Number of Segments 7
Number of Characters 2
Display Type 7-Segment
Wavelength - Peak 650nm
Luminous Intensity 16 mcd
Current - Test 10mA
Forward Current 20mA
Element Configuration Common Anode
Power Dissipation-Max 60mW
Operating Supply Voltage 2V
Number of Functions 2
Subcategory LED Displays
Color Red
Min Operating Temperature -25°C
Max Operating Temperature 75°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Size / Dimension 0.748 Hx0.984W x 0.315 D 19.00mmx25.00mmx8.00mm
Published 2008
Packaging Bulk

Physical

Number of Pins 18
Package / Case 18-DIP
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
