LB-302MF
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.400, 10.16mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7SEG 7.62MM 2DGT GRN CA
PDF
/
Buying Options
Total Price: USD $9.26
Unit Price: USD $9.263822
≥1 USD $9.263822
≥200 USD $3.697126
≥500 USD $3.573714
≥1000 USD $3.512008
Inventory: 5908
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 15.0114mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 2
Display Type 7-Segment
Wavelength - Peak 563nm
Luminous Intensity 9 mcd
Current - Test 10mA
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Anode
Power Dissipation-Max 60mW
Operating Supply Voltage 2.1V
Number of Contacts 18
Number of Functions 3
Subcategory LED Displays
Color Green
Min Operating Temperature -25°C
Max Operating Temperature 75°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e1
Size / Dimension 0.591 Hx0.610W x 0.283 D 15.00mmx15.50mmx7.20mm
Published 2000
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.400, 10.16mm)
Supply Chain
Factory Lead Time 10 Weeks
