LA-601BB
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.400, 10.16mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7SEG 14.6MM 1DGT BLUE CA
PDF
/
Buying Options
Total Price: USD $15.97
Unit Price: USD $15.972
≥1 USD $15.972
Inventory: 81
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Character Height 14.6mm
Height 18.9992mm
Technical
Character Width 8.3mm
Common Pin Common Anode
Digit/Alpha Size 0.58 14.60mm
Number of Segments 7
Number of Characters 1
Forward Voltage-Max 4.2V
Display Type 7-Segment
Wavelength - Peak 470nm
Millicandela Rating 56mcd
Luminous Intensity 56 mcd
Forward Current 10mA
Element Configuration Common Anode
Power Dissipation-Max 42mW
Operating Supply Voltage 3.6V
Number of Functions 1
Subcategory LED Displays
Color Blue
Min Operating Temperature -25°C
Max Operating Temperature 75°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e1
Size / Dimension 0.748 Hx0.492W x 0.315 D 19.00mmx12.50mmx8.00mm
Published 2008
Packaging Bulk
Physical
Package / Case 10-DIP (0.400, 10.16mm)
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
