MAN4740A
RoHS
/
Package 14-DIP (0.300, 7.62mm), 11 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG DISP CC RED RHDP .4"
PDF
/
Inventory: 999
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 14-DIP (0.300, 7.62mm), 11 Leads
Technical
Packaging Bulk
Published 1997
Size / Dimension 0.738 Hx0.386W x 0.200 D 18.75mmx9.80mmx5.08mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Operating Supply Voltage 2.2V
Power Dissipation-Max 480mW
Element Configuration Common Cathode
Voltage - Forward (Vf) (Typ) 1.6V
Forward Current 240mA
Current - Test 20mA
Forward Voltage 1.6V
Luminous Intensity 350 μcd
Millicandela Rating 0.35mcd
Illumination Color Red
Wavelength - Peak 660nm
Display Type 7-Segment
Wavelength 660 nm
Number of Characters 1
Digit/Alpha Size 0.40 10.16mm
Common Pin Common Cathode
Character Width 10.16mm
Dimensions
Height 5.08mm
Length 18.7452mm
Width 9.8044mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
