LDS-C305RI
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7SEG .30" SGL 700NM RED CC
PDF
/
Inventory: 8363
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 14-DIP (0.300, 7.62mm), 10 Leads
Technical
Packaging Bulk
Published 2004
Size / Dimension 0.752 Hx0.401W x 0.240 D 19.10mmx10.18mmx6.10mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Color Red
Subcategory LED Displays
Number of Contacts 10
Operating Supply Voltage 2.5V
Power Dissipation-Max 120mW
Element Configuration Common Cathode
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 25mA
Current - Test 10mA
Luminous Intensity 880 μcd
Millicandela Rating 0.88mcd
Wavelength - Peak 700nm
Display Type 7-Segment
Forward Voltage-Max 2.6V
Number of Characters 1
Digit/Alpha Size 0.31 7.87mm
Common Pin Common Cathode
Character Width 7.62mm
Dimensions
Height 6.1mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
