LTS-549AWC
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 1DGT RED LC 0.52" CC
PDF
/
Inventory: 2886
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 11.85mm
Height 17.5514mm
Technical
Dominant Wavelength 638 nm
Common Pin Common Cathode
Digit/Alpha Size 0.47 11.85mm
Number of Characters +/-1 (overflow)
Forward Voltage-Max 2.4V
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 660nm
Luminous Intensity 3.75 mcd
Current - Test 5mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.7V
Power Dissipation 75mW
Element Configuration Common Cathode
Number of Elements 6
Depth 12.4mm
Number of Functions 0.5
Subcategory LED Displays
HTS Code 8541.40.20.00
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Size / Dimension 0.691 Hx0.488W x 0.276 D 17.55mmx12.40mmx7.00mm
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
