LTP-537JD
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.500, 12.70mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY ALPHA-NUM RED LC .50" CC
PDF
/
Inventory: 7965
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 12.7mm
Height 24.9936mm
Technical
Dominant Wavelength 639 nm
Common Pin Common Cathode
Digit/Alpha Size 0.50 12.70mm
Number of Characters 1
Display Type 16-Segment, Alphanumeric
Forward Current-Max 0.025A
Wavelength - Peak 650nm
Millicandela Rating 0.7mcd
Luminous Intensity 700 μcd
Current - Test 20mA
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation-Max 70mW
Reach Compliance Code unknown
Number of Functions 1
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.984 Hx0.630W x 0.374 D 25.00mmx16.00mmx9.50mm
Published 2001
Packaging Tube
Physical
Number of Pins 18
Package / Case 18-DIP (0.500, 12.70mm)
Supply Chain
Factory Lead Time 12 Weeks
