SC56-21SRWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED SB. Red CC 10-Pin DIP Module Tube
PDF
/
Inventory: 7871
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 14.2mm
Height 19.05mm
Technical
Character Width 14.224mm
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 1
Forward Voltage-Max 2.5V
Display Type 7-Segment
Power Consumption 75mW
Wavelength - Peak 660nm
Millicandela Rating 34mcd
Luminous Intensity 34 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Cathode
Power Dissipation-Max 75mW
Operating Supply Voltage 1.85V
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.750 Hx0.500W x 0.315 D 19.05mmx12.70mmx8.00mm
Published 2011
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Supply Chain
Factory Lead Time 12 Weeks
