SC23-11SRWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (2.367, 60.10mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 660NM RED NUMERIC 2.3"
PDF
/
Buying Options
Total Price: USD $11.3
Unit Price: USD $11.299791
≥1 USD $11.299791
≥10 USD $10.660176
≥100 USD $10.056774
≥500 USD $9.48752
≥1000 USD $8.950485
Inventory: 1169
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Package / Case 10-DIP (2.367, 60.10mm)
Technical
Packaging Tube
Published 2011
Size / Dimension 2.756 Hx1.890W x 0.472 D 70.00mmx48.00mmx12.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature IC COMPATIBLE
Number of Functions 1
Operating Supply Voltage 7.4V
Power Dissipation-Max 300mW
Element Configuration Common Cathode
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 190 mcd
Millicandela Rating 190mcd
Wavelength - Peak 660nm
Power Consumption 300mW
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 2.24 56.90mm
Common Pin Common Cathode
Dimensions
Height 70.0024mm
Compliance
RoHS Status ROHS3 Compliant
