SC08-21EWA
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm), 15 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Single Red 625nm Common Cathode
PDF
/
Buying Options
Total Price: USD $2.65
Unit Price: USD $2.6488
≥1 USD $2.6488
≥10 USD $1.76616
≥100 USD $1.359248
≥500 USD $1.228674
≥1000 USD $1.055894
≥3000 USD $0.998298
Inventory: 1134
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 24.9936mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 1
Display Type 7-Segment
Power Consumption 75mW
Wavelength - Peak 627nm
Millicandela Rating 8mcd
Luminous Intensity 8 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Element Configuration Common Cathode
Number of Functions 1
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.984 Hx0.732W x 0.417 D 25.00mmx18.60mmx10.60mm
Published 2011
Packaging Tube
Physical
Package / Case 18-DIP (0.600, 15.24mm), 15 Leads
Supply Chain
Factory Lead Time 8 Weeks
