SC08-12SRWA
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Single Red 640nm Common Cathode
PDF
/
Inventory: 6954
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Package / Case 16-DIP (0.600, 15.24mm)
Technical
Packaging Tube
Published 2007
Size / Dimension 1.091 Hx0.787W x 0.331 D 27.70mmx20.00mmx8.40mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Color Red
Additional Feature IC COMPATIBLE
Number of Functions 1
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Dissipation-Max 75mW
Element Configuration Common Cathode
Voltage - Forward (Vf) (Typ) 1.85V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Luminous Intensity 36 mcd
Wavelength - Peak 660nm
Forward Current-Max 0.03A
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 0.80 20.32mm
Common Pin Common Cathode
Dimensions
Height 27.7114mm
Compliance
RoHS Status ROHS3 Compliant
