SC05-11SURKWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
KINGBRIGHT SC05-11SURKWA 7-Segment LED Display, Mechanically Rugged, Red, 30 mA, 1.95 V, 30000 cd, 1, 12.7 mm
PDF
/
Buying Options
Total Price: USD $1.72
Unit Price: USD $1.716
≥1 USD $1.716
≥10 USD $1.14488
≥100 USD $0.88095
≥500 USD $0.796365
≥1000 USD $0.684376
≥3000 USD $0.647046
Inventory: 177
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 12.7mm
Height 18.9992mm
Technical
Character Width 7.3mm
Common Pin Common Cathode
Digit/Alpha Size 0.50 12.70mm
Number of Segments 7
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 645nm
Millicandela Rating 69mcd
Luminous Intensity 30 mcd
Current - Test 20mA
Forward Current 30mA
Voltage - Forward (Vf) (Typ) 1.95V
Element Configuration Common Cathode
Power Dissipation-Max 75mW
Number of Functions 1
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.748 Hx0.500W x 0.315 D 19.00mmx12.70mmx8.00mm
Published 2001
Packaging Tube
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
