EADSD056GA1
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
7SEG DISPLAY 2DIGIT Y/G 0.58" CC
PDF
/
Buying Options
Total Price: USD $9.81
Unit Price: USD $9.807363
≥1 USD $9.807363
≥200 USD $3.913755
≥500 USD $3.782465
≥1000 USD $3.718133
Inventory: 4579
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Package / Case 10-SMD, No Lead
Technical
Packaging Tape & Reel (TR)
Published 2014
Size / Dimension 0.748 Hx0.984W x 0.124 D 19.00mmx25.00mmx3.15mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color Yellow-Green
Number of Functions 2
Operating Temperature (Max) 105°C
Operating Temperature (Min) -40°C
Power Dissipation-Max 60mW
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Luminous Intensity 12.5 mcd
Wavelength - Peak 575nm
Display Type 7-Segment
Number of Characters 2
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Dimensions
Height 18.9992mm
Compliance
RoHS Status ROHS3 Compliant
