HDSP-U503
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.209, 5.30mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Green CC 10-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.3959
Inventory: 152
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Character Height 8mm
Viewing Area (height) 8mm
Height 10.9982mm
Technical
Character Width 4mm
Dominant Wavelength 571 nm
Common Pin Common Cathode
Digit/Alpha Size 0.31 8.00mm
Number of Segments 7
Number of Characters 1
Forward Voltage-Max 2.5V
Reverse Voltage 50V
Display Type 7-Segment
Wavelength - Peak 566nm
Luminous Intensity 6.8 mcd
Current - Test 10mA
Forward Current 30mA
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 105mW
Element Configuration Common Cathode
Number of Elements 8
Operating Supply Voltage 2.3V
Depth 7.1mm
Number of Functions 1
Subcategory LED Displays
Color Green
Min Operating Temperature -20°C
Max Operating Temperature 90°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.433 Hx0.280W x 0.197 D 11.00mmx7.10mmx5.00mm
Published 2012
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.209, 5.30mm)
Mount Through Hole
Supply Chain
Factory Lead Time 22 Weeks
