APHF1608SEEQBDZGKC
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED RGB CLEAR 4SMD
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.616
≥1 USD $0.616
≥10 USD $0.40216
≥100 USD $0.263472
≥500 USD $0.207979
≥1000 USD $0.194119
Inventory: 1284
Minimum: 1
-
+
Technical Details
Technical
Millicandela Rating 120mcd Red, 480mcd Green, 60mcd Blue
Lens Transparency Clear
Wavelength - Peak 630nm Red 515nm Green 460nm Blue
Lens Color Colorless
Forward Current-Max 0.02A
Overall Height 0.5mm
Wavelength - Dominant 621nm Red 525nm Green 465nm Blue
Luminous Intensity 120.0/480.0/60.0 mcd
Lens Size 1.60mmx0.80mm
Lens Style Rectangle with Flat Top
Current - Test 20mA Red 20mA Green 20mA Blue
Optoelectronic Device Type TRIPLE COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 2V Red 3.3V Green 3.3V Blue
Configuration Common Anode
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 1
Packing Method TR, 7 INCH
Color Red, Green, Blue (RGB)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 1.60mm Lx0.80mm W
Series HELI Colour
Published 2017
Packaging Tape & Reel (TR)
Dimensions
Height (Max) 0.60mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
