HDSP-N155
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Red 637nm .8in 7 Segment
PDF
/
Inventory: 2134
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 18-DIP (0.600, 15.24mm), 12 Leads
Technical
Packaging Bulk
Published 2010
Size / Dimension 1.090 Hx0.786W x 0.330 D 27.69mmx19.96mmx8.38mm
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Red
Number of Functions 1
Reach Compliance Code compliant
Operating Temperature (Min) -20°C
Power Dissipation-Max 96mW
Voltage - Forward (Vf) (Typ) 1.8V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Millicandela Rating 14mcd
Wavelength - Peak 645nm
Forward Current-Max 0.04A
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 0.80 20.32mm
Common Pin Common Cathode
Dimensions
Display Height 20.32mm
Compliance
RoHS Status RoHS Compliant
