HDSP-H3E3
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7SEGMENT RED
PDF
/
Buying Options
Total Price: USD $1.45
Unit Price: USD $1.454693
≥1 USD $1.454693
≥200 USD $0.580302
≥500 USD $0.561921
≥1000 USD $0.551418
Inventory: 2668
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 13.9954mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.36 9.14mm
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 634nm
Luminous Intensity 15 mcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 52mW
Color Red
Terminal Finish Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.551 Hx0.295W x 0.335 D 14.00mmx7.50mmx8.50mm
Packaging Bulk
Physical
Package / Case 10-DIP (0.200, 5.08mm)
Supply Chain
Factory Lead Time 16 Weeks
Alternative Model
