HDSP-H3A3
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7SEGMENT DEEP RED
PDF
/
Inventory: 5314
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Package / Case 10-DIP (0.200, 5.08mm)
Technical
Packaging Bulk
Published 2017
Size / Dimension 0.551 Hx0.295W x 0.335 D 14.00mmx7.50mmx8.50mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin (Sn)
Color Red
Power Dissipation-Max 52mW
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Luminous Intensity 13 mcd
Wavelength - Peak 644nm
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 0.36 9.14mm
Common Pin Common Cathode
Dimensions
Height 13.9954mm
Compliance
RoHS Status ROHS3 Compliant
