HDSP-C3L1
RoHS
/
Package 10-DIP (0.200, 5.08mm), 8 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
BROADCOM LIMITED HDSP-C3L1 7-Segment LED Display, Orange, 20 mA, 2.15 V, 900 cd, 1, 9.1 mm
PDF
/
Inventory: 1969
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Character Height 9.1mm
Viewing Area (height) 9.1mm
Height 13.9954mm
Technical
Dominant Wavelength 605 nm
Common Pin Common Anode
Digit/Alpha Size 0.36 9.14mm
Number of Characters 1
Forward Voltage-Max 2.3V
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 610nm
Millicandela Rating 0.9mcd
Luminous Intensity 900 μcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.15V
Power Dissipation 57.5mW
Element Configuration Common Anode
Number of Elements 8
Operating Temperature (Min) -40°C
Reach Compliance Code unknown
Depth 7.5mm
Number of Functions 1
Subcategory LED Displays
Additional Feature HIGH RELIABILITY
Color Orange
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 0.551 Hx0.295W x 0.335 D 14.00mmx7.50mmx8.50mm
Published 1996
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.200, 5.08mm), 8 Leads
Mount Through Hole
