HDSP-A213
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Hi-Eff. Red CC 10-Pin DIP
PDF
/
Buying Options
Total Price: USD $3.8
Unit Price: USD $3.800846
≥1 USD $3.800846
≥200 USD $1.5164
≥400 USD $1.466509
≥1000 USD $1.441564
Inventory: 962
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.200, 5.08mm)
Number of Pins 10
Technical
Packaging Bulk
Published 2006
Size / Dimension 0.500 Hx0.300W x 0.240 D 12.70mmx7.62mmx6.09mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Red
Subcategory LED Displays
Number of Functions 1
Depth 7.62mm
Number of Elements 8
Element Configuration Common Cathode
Power Dissipation 105mW
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 5mA
Current - Test 20mA
Luminous Intensity 5.39 mcd
Wavelength - Peak 635nm
Display Type 7-Segment
Reverse Voltage 30V
Forward Voltage-Max 2V
Number of Characters 1
Digit/Alpha Size 0.30 7.62mm
Common Pin Common Cathode
Dominant Wavelength 626 nm
Dimensions
Height 12.7mm
Viewing Area (height) 7.62mm
Compliance
RoHS Status ROHS3 Compliant
