HDSP-7802-JK000
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
7-Segment 1 SMART/NORMAL 7SEG NUMERIC LED DISPLAY Green LED Character Numeric Display Module 2.5V 10mA 6.8mcd 105mW
PDF
/
Inventory: 3116
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 10-DIP (0.200, 5.08mm)
Technical
Packaging Bulk
Published 2006
Size / Dimension 0.500 Hx0.300W x 0.240 D 12.70mmx7.62mmx6.09mm
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Green
Subcategory LED Displays
Number of Functions 1
Reach Compliance Code compliant
Operating Temperature (Min) -40°C
Power Dissipation-Max 105mW
Voltage - Forward (Vf) (Typ) 2.1V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 10mA
Millicandela Rating 6.8mcd
Wavelength - Peak 566nm
Forward Current-Max 0.03A
Display Type 7-Segment
Forward Voltage-Max 2.5V
Number of Characters 1
Digit/Alpha Size 0.30 7.62mm
Common Pin Common Anode
Dimensions
Display Height 7.6mm
Compliance
RoHS Status RoHS Compliant
