HDSP-7401
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 7.6MM CA YELLOW
PDF
/
Buying Options
Total Price: USD $2.91
Unit Price: USD $2.9128
≥1 USD $2.9128
≥10 USD $2.061664
≥100 USD $1.688456
≥500 USD $1.423418
≥1000 USD $1.305612
≥3000 USD $1.251624
Inventory: 1175
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Character Height 7.6mm
Viewing Area (height) 7.62mm
Height 12.7mm
Technical
Dominant Wavelength 586 nm
Common Pin Common Anode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 1
Forward Voltage-Max 2.5V
Reverse Voltage 50V
Display Type 7-Segment
Wavelength - Peak 583nm
Millicandela Rating 2.74mcd
Luminous Intensity 5.39 mcd
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 2.2V
Power Dissipation 80mW
Element Configuration Common Anode
Number of Elements 8
Operating Supply Voltage 2V
Depth 7.62mm
Number of Functions 1
Subcategory LED Displays
Color Yellow
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.500 Hx0.300W x 0.240 D 12.70mmx7.62mmx6.09mm
Published 2006
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.200, 5.08mm)
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
