HDSP-561E
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Hi-Eff. Red CA 10-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $1.63
Unit Price: USD $1.628
≥1 USD $1.628
≥10 USD $1.0296
≥100 USD $0.761834
≥500 USD $0.700058
≥1000 USD $0.576514
≥3000 USD $0.547694
Inventory: 3216
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.600, 15.24mm)
Number of Pins 10
Technical
Packaging Bulk
Published 2007
Size / Dimension 0.689 Hx0.482W x 0.276 D 17.50mmx12.25mmx7.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Color Red
Subcategory LED Displays
Depth 9.7mm
Operating Supply Voltage 1.9V
Number of Elements 8
Power Dissipation-Max 105mW
Element Configuration Common Anode
Power Dissipation 105mW
Optoelectronic Device Type 7 SEG NUMERIC LED DISPLAY
Forward Current 30mA
Current - Test 20mA
Luminous Intensity 1.8 mcd
Wavelength - Peak 635nm
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 1
Digit/Alpha Size 0.52 13.21mm
Common Pin Common Anode
Dominant Wavelength 625 nm
Dimensions
Height 17.5006mm
Viewing Area (height) 13mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
