HDSP-561C
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Red CA 10-Pin
PDF
/
Buying Options
Total Price: USD $1.49
Unit Price: USD $1.491454
≥1 USD $1.491454
≥320 USD $0.596057
≥640 USD $0.576363
≥960 USD $0.56586
Inventory: 4167
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.600, 15.24mm)
Number of Pins 10
Technical
Packaging Bulk
Published 2006
Size / Dimension 0.689 Hx0.482W x 0.276 D 17.50mmx12.25mmx7.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Red
Number of Functions 1
Depth 12.25mm
Number of Elements 8
Element Configuration Common Anode
Voltage - Forward (Vf) (Typ) 1.9V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 50mA
Current - Test 20mA
Luminous Intensity 36 mcd
Millicandela Rating 18mcd ~ 36mcd
Wavelength - Peak 635nm
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 1
Digit/Alpha Size 0.51 13.00mm
Common Pin Common Anode
Dominant Wavelength 626 nm
Dimensions
Height 17.5006mm
Viewing Area (height) 13mm
Compliance
RoHS Status ROHS3 Compliant
