HDSP-511A
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Red CA 10-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $1.72
Unit Price: USD $1.716
≥1 USD $1.716
≥10 USD $1.14312
≥100 USD $0.879824
≥500 USD $0.720755
≥1000 USD $0.683478
≥3000 USD $0.646193
Inventory: 5625
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Plating Tin
Mount Through Hole
Package / Case 10-DIP (0.600, 15.24mm)
Number of Pins 10
Technical
Packaging Bulk
Published 2011
Size / Dimension 0.673 Hx0.488W x 0.315 D 17.10mmx12.40mmx8.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Red
Number of Functions 1
Depth 17.1mm
Operating Supply Voltage 1.85V
Number of Elements 8
Power Dissipation-Max 30mW
Element Configuration Common Anode
Power Dissipation 30mW
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 10mA
Current - Test 20mA
Luminous Intensity 6.5 mcd
Wavelength - Peak 660nm
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 1
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Anode
Dominant Wavelength 643 nm
Dimensions
Height 17.0942mm
Viewing Area (height) 14.22mm
Compliance
RoHS Status ROHS3 Compliant
