HDSP-311Y
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Yellow CA 14-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.3943
≥1 USD $1.3943
≥340 USD $0.55667
≥680 USD $0.538289
≥1020 USD $0.529099
Inventory: 1576
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 10.16mm
Height 18.7452mm
Technical
Dominant Wavelength 590 nm
Common Pin Common Anode
Digit/Alpha Size 0.40 10.16mm
Number of Characters 1
Forward Voltage-Max 2.6V
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 595nm
Luminous Intensity 1.5 mcd
Current - Test 20mA
Forward Current 10mA
Optoelectronic Device Type 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.15V
Power Dissipation 52mW
Element Configuration Common Anode
Number of Elements 8
Depth 9.8mm
Subcategory LED Displays
Color Yellow
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.738 Hx0.386W x 0.201 D 18.75mmx9.80mmx5.10mm
Packaging Bulk
Physical
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm), 10 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
