HDSP-311E
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Hi-Eff. Red CA 14-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $1.63
Unit Price: USD $1.628
≥1 USD $1.628
≥10 USD $1.0296
≥100 USD $0.761922
≥500 USD $0.700146
≥1000 USD $0.576594
≥3000 USD $0.547765
Inventory: 1486
Minimum: 1
-
+
Technical Details
Technical
Number of Elements 8
Element Configuration Common Anode
Power Dissipation 65mW
Voltage - Forward (Vf) (Typ) 2.05V
Optoelectronic Device Type 7 SEG NUMERIC LED DISPLAY
Forward Current 10mA
Current - Test 20mA
Luminous Intensity 3.2 mcd
Wavelength - Peak 635nm
Display Type 7-Segment
Reverse Voltage 5V
Forward Voltage-Max 2.4V
Number of Characters 1
Digit/Alpha Size 0.40 10.16mm
Common Pin Common Anode
Dominant Wavelength 620 nm
Depth 9.8mm
Subcategory LED Displays
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.738 Hx0.386W x 0.201 D 18.75mmx9.80mmx5.10mm
Packaging Bulk
Dimensions
Height 18.7452mm
Viewing Area (height) 10.16mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm), 10 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
