APT2012SRCPRV

Kingbright
RoHS
RoHS RoHS compliant
Package 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description LED RED CLEAR CHIP SMD
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.09405
≥1 USD $0.09405
≥10 USD $0.0779
≥100 USD $0.07505
≥500 USD $0.07315
≥1000 USD $0.0703
≥5000 USD $0.0627
Inventory: 46232
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Height 850μm

Technical

Number of LEDs 1
Wavelength - Dominant 640nm
Reverse Voltage 5V
Lens Color Colorless
Wavelength - Peak 655nm
Lens Transparency Clear
Millicandela Rating 30mcd
Luminous Intensity 100 mcd
Lens Size 1.30mmx1.25mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Forward Current 30mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 1.85V
Power Dissipation 75mW
Configuration Standard
Case Code (Imperial) 0805
Case Code (Metric) 2012
Number of Functions 1
Packing Method TAPE AND REEL 7"
Power Rating 75mW
Subcategory Visible LEDs
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 2.00mm Lx1.25mm W
Published 2007
Packaging Tape & Reel (TR)

Physical

Shape RECTANGULAR
Number of Pins 2
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
