HDSM-541W
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED DISP, SMD, DUAL, 14.2MM, WHITE, CA
PDF
/
Buying Options
Total Price: USD $13.39
Unit Price: USD $13.386328
≥1 USD $13.386328
≥200 USD $5.34219
≥500 USD $5.163636
≥1000 USD $5.075671
Inventory: 6677
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Character Height 14mm
Viewing Area (height) 14.22mm
Height 16.9926mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 2
Forward Voltage-Max 3.8V
Reverse Voltage 5V
Display Type 7-Segment
Luminous Intensity 44 mcd
Current - Test 5mA
Forward Current 25mA
Voltage - Forward (Vf) (Typ) 2.95V
Power Dissipation 39mW
Element Configuration Common Anode
Number of Elements 16
Depth 19mm
Number of Functions 2
Subcategory LED Displays
Color White
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.669 Hx0.984W x 0.148 D 17.00mmx25.00mmx3.75mm
Published 2014
Packaging Tape & Reel (TR)
Physical
Number of Pins 10
Package / Case 10-SMD, No Lead
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
