ADSP-H3E3
RoHS
/
Package 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
7SEG DISPLAY 1DIGIT RED 0.36" CC
PDF
/
Inventory: 6911
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 10-DIP (0.200, 5.08mm)
Number of Pins 10
Technical
Packaging Tube
Published 2012
Size / Dimension 0.551 Hx0.295W x 0.335 D 14.00mmx7.50mmx8.50mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Power Dissipation-Max 52mW
Voltage - Forward (Vf) (Typ) 2V
Current - Test 20mA
Forward Voltage 2V
Luminous Intensity 15 mcd
Millicandela Rating 15mcd
Wavelength - Peak 634nm
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 0.36 9.14mm
Common Pin Common Cathode
Dominant Wavelength 625 nm
Dimensions
Height 13.9954mm
Width 7.493mm
Viewing Area (height) 9.1mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
