A6TR-6101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH PIANO DIP SPST 25MA 24V
PDF
/
Buying Options
Total Price: USD $5.84
Unit Price: USD $5.838466
≥1 USD $5.838466
≥186 USD $2.330398
≥496 USD $2.252936
≥992 USD $2.213549
Inventory: 4776
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Height Above Board 0.197 5.00mm
Actuator Length 900μm
Width 6.2mm
Length 0.596 15.14mm
Height 4.2mm
Technical
Actuator Level Flush, Recessed
Washable No
Switch Action MOMENTARY
Number of Switch Sections 6
Contact Current Rating 25mA
Mechanical Life 1000 cycles
Max Voltage Rating (DC) 24V
Electrical Life 1,000 Cycles
Max Current Rating 25mA
Contact Current(DC)-Max 0.025A
Contact Resistance 200mOhm
Circuit SPST
Actuator Type Piano
Termination Style PC Pin
Current Rating 25mA
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Additional Feature LOW PROFILE
Voltage - Rated 24VDC
Number of Positions 6
ECCN Code EAR99
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series A6TR
Published 2008
Packaging Tube
Operating Temperature -20°C~70°C
Physical
Weight 760mg
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 16 Weeks
