A6E-9101
RoHS
/
Package DIP
Category Switches / DIP Switches
Description
OMRON ELECTRONIC COMPONENTS A6E9101 DIP / SIP Switch, SPST, Through Hole, 9 Circuits, DIP Unsealed, 24 VDC
PDF
/
Buying Options
Total Price: USD $14.06
Unit Price: USD $14.05722
≥1 USD $14.05722
≥209 USD $5.608709
≥494 USD $5.422277
≥1007 USD $5.329061
Inventory: 9076
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Height Above Board 0.236 6.00mm
Actuator Length 0m
Length 0.961 24.41mm
Technical
Actuator Level Flush, Recessed
Washable No
Contact Function ON-OFF
PCB Hole Count 18
Number of Switch Sections 1
Contact Timing MAKE-BEFORE-BREAK
Contact Current Rating 25mA
Mechanical Life 1,000 Cycles
Max Voltage Rating (DC) 24V
Electrical Life 1,000 Cycles
Dielectric Withstanding Voltage 500VAC V
Sealing BOTTOM SEALED
Contact Current(DC)-Max 0.025A
Insulation Resistance 100000000Ohm
Contact Resistance 200mOhm
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Current Rating 25mA
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Voltage - Rated 24VDC
Number of Positions 9
Termination PC Pins
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
Feature Sealed - Flux Protection
JESD-609 Code e4
Series A6E
Published 2004
Packaging Tube
Operating Temperature -20°C~70°C
Physical
Package / Case DIP
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
Alternative Model
