JS0304PP4-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPST 4 Piano 0.025A 24VDC PC Pins 2000Cycles 2.54mm Thru-Hole Stick/Tube
PDF
/
Buying Options
Total Price: USD $2.57
Unit Price: USD $2.5696
≥1 USD $2.5696
≥10 USD $2.42264
≥100 USD $2.202402
≥500 USD $1.908799
≥1000 USD $1.730502
≥3000 USD $1.604636
Inventory: 71
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole, Right Angle
Body Material Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature -25°C~70°C
Packaging Tube
Published 2010
Series JS
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Number of Positions 4
Voltage - Rated 24VDC
Voltage - Rated DC 24V
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 2.54mm
Current Rating 25mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Piano
Circuit SPST
Max Current Rating 25mA
Electrical Life 2,000 Cycles
Mechanical Life 2,000 Cycles
Washable No
Actuator Level Raised
Dimensions
Length 0.446 11.33mm
Height Above Board 0.362 9.20mm
Compliance
RoHS Status ROHS3 Compliant
