S-2050W
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH ROTARY DIP SP4T 100MA 5V
PDF
/
Buying Options
Total Price: USD $9.26
Unit Price: USD $9.258571
≥1 USD $9.258571
≥200 USD $3.694501
≥500 USD $3.571088
≥1000 USD $3.510695
Inventory: 2493
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Body Material Polybutylene Terephthalate (PBT)
Technical
Operating Temperature -25°C~70°C
Packaging Tray
Published 2016
Series S-2050
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Number of Positions 4
Max Operating Temperature 70°C
Min Operating Temperature -25°C
Voltage - Rated 5VDC
Voltage - Rated DC 5V
Current Rating (Amps) 100mA
Pitch 0.100 2.54mm Full
Current Rating 100mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Rotary for Tool
Circuit SP4T
Electrical Life 500 Cycles
Throw Configuration SP4T
Washable Yes
Actuator Level Flush, Recessed
Dimensions
Length 0.393 10.00mm
Height Above Board 0.275 6.99mm
Compliance
RoHS Status ROHS3 Compliant
